How to remove and install the fuel pump on BMW X3?

For removing and installing the fuel pump, there is need to first unlatch the fuel tank service cap. Unscrew the connectors with advisable marginal force using a screwdriver. To remove the fuel pump wiring disconnected it with the help of BMW special tool 610307 which is present at the blue electrical connector positioned inside the tank. This is crucial for the simple reason that the connector on the fuel pump should not be removed at all because the replacement fuel pump comes with the connector attached to it. For reassembly it will be constructive to preserve the position of the wiring in the blue connector. When carrying out job within fuel tank, pull the tabs in the direction as shown to disconnect the line and to remove the fuel line, pull the tabs for quick connector. Pull the suction-jet line in the indicated direction to release the retaining lug, and simultaneous with this, push the lug to the rear of the fuel tank, thus lifting the fuel pump in conjunction with the surge chamber. For installation the sequence has to be done in the reverse order that it was removed and make sure the correct position of fuel pump before the guides and make sure the mounting lug lock into the fuel pump correctly. The fuel pump has an electrical wiring that should be plugged into the blue connector and the connectors for the fuel line must click into place. For the fuel pump not to be damaged it is recommended to refill the tank with at least 5 liters (1.5 gallons) of fuel before the engine is ignited after the work.

Genuine BMW X3 Fuel Pump

Gas Pump

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Series

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

15 Fuel Pumps found

View related parts
BMW X3 Fuel Pump Module Assembly, Right
Part Number: 16117319502
$424.15 MSRP: $585.71
You Save: $161.56 (28%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Delivery Unit W/Fill Level Sensor, Right; Fuel Pump
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2011-2017 BMW X3 | sDrive28i(F25), xDrive28i(F25), xDrive35i(F25)
View related parts
BMW X3 High Pressure Fuel Pump
Part Number: 13517642466
$987.69 MSRP: $1292.32
You Save: $304.63 (24%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: High-Pressure Pump; Fuel Pump
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2018-2019 BMW X3 | M40i(G01), sDrive30i(G01), xDrive30i(G01)
View related parts
BMW X3 Fuel Pump Right
Part Number: 16117314804
$424.15 MSRP: $585.71
You Save: $161.56 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Delivery Unit W/Fill Level Sensor, Right; Fuel Pump
- Position: Passenger Side
- Replaces: 16-11-7-285-443
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2011-2017 BMW X3 | xDrive28i(F25), xDrive35i(F25)
View related parts
BMW X3 Fuel Pump Right
Part Number: 16117159604
$366.31 MSRP: $505.84
You Save: $139.53 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Delivery Unit With In-Tank Pump, Right; Fuel Pump, Seal
- Position: Passenger Side
- Replaces: 16-14-6-766-157
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2004-2006 BMW X3 | 2.5i(E83), 3.0i(E83)
View related parts
BMW X3 Fuel Tank Pump Supply Sender Module Assembly
Part Number: 16117214881
$445.36 MSRP: $615.00
You Save: $169.64 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Delivery Module
- Replaced by: 16119468611
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2018-2020 BMW X3 | M40i(G01), sDrive30i(G01), xDrive30i(G01)
View related parts
BMW X3 Fuel Pump Right
Part Number: 16117198406
$366.31 MSRP: $505.84
You Save: $139.53 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Delivery Unit With In-Tank Pump, Right; Fuel Pump
- Position: Passenger Side
- Replaces: 16-11-7-186-453
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2007-2010 BMW X3 | 3.0si(E83)
View related parts
BMW X3 Electric Fuel Pump, Right
Part Number: 16117314808
$424.15 MSRP: $585.71
You Save: $161.56 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Delivery Unit W/Fill Level Sensor, Right; Fuel Pump
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2015-2017 BMW X3 | xDrive28d(F25)
View related parts
BMW X3 High Pressure Fuel Pump
Part Number: 13518631642
$1037.06 MSRP: $1356.91
You Save: $319.85 (24%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: High-Pressure Pump; Fuel Pump, Injection Pump
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2020-2024 BMW X3 | 4 Cyl 2.0 L GAS, 4 Cyl 2.0 L PLUG-IN HYBRID EV-GAS (PHEV), 6 Cyl 3.0 L GAS, 6 Cyl 3.0 L MILD HYBRID EV-GAS (MHEV), M40i(G01), sDrive30i(G01), xDrive30e(G01), xDrive30i(G01)
View related parts
BMW X3 High Pressure Fuel Pump
Part Number: 13518604231
$996.37 MSRP: $1292.32
You Save: $295.95 (23%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: High-Pressure Pump; Fuel Pump
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2011-2017 BMW X3 | xDrive35i(F25)
View related parts
BMW X3 High Pressure Fuel Pump
Part Number: 13518604229
$996.37 MSRP: $1292.32
You Save: $295.95 (23%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: High-Pressure Pump; Fuel Pump
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2013-2017 BMW X3 | sDrive28i(F25), xDrive28i(F25)
View related parts
BMW X3 Supply Module
Part Number: 16119468611
$445.36 MSRP: $615.00
You Save: $169.64 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Pump
- Replaces: 16-11-7-214-881
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2018-2024 BMW X3 | 4 Cyl 2.0 L GAS, 6 Cyl 3.0 L GAS, 6 Cyl 3.0 L MILD HYBRID EV-GAS (MHEV), M40i(G01), sDrive30i(G01), xDrive30i(G01)
View related parts
BMW X3 Supply Module
Part Number: 16119468628
$445.36 MSRP: $615.00
You Save: $169.64 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Pump
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2021-2024 BMW X3 | 6 Cyl 3.0 L GAS
View related parts
BMW X3 Fuel Pump Right
Part Number: 16117314803
$424.15 MSRP: $585.71
You Save: $161.56 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Delivery Unit W/Fill Level Sensor, Right
- Position: Passenger Side
- Replaces: 16-11-7-285-442
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2011-2012 BMW X3 | xDrive28i(F25)
View related parts
BMW X3 Supply Module
Part Number: 16117214887
$378.74 MSRP: $523.00
You Save: $144.26 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Pump
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2020-2021 BMW X3 | 4 Cyl 2.0 L PLUG-IN HYBRID EV-GAS (PHEV), xDrive30e(G01)
View related parts
BMW X3 Supply Module
Part Number: 16115A64841
$466.57 MSRP: $644.29
You Save: $177.72 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Fuel Pump Assembly
- Warranty: This genuine part is guaranteed by BMW's factory warranty.
Fits the following Vehicles:
- 2025 BMW X3 | 6 Cyl 3.0 L MILD HYBRID EV-GAS (MHEV)

BMW X3 Fuel Pump

BMW X3 Fuel Pump is the lifeline of the vehicle and transports gasoline from the tank to the engine with the exact pressure required for clean combustion. Early X3 models with carbureted setups applied a camshaft-driven mechanical Fuel Pump on the engine block that applied a lever and diaphragm to draw fuel at low pressure, which was ideal for a float bowl. As injection systems became standard, BMW switched to an in-tank electric Fuel Pump coupled with the sending unit, in which submersion in fuel keeps it cool and the ECU controls voltage to deliver 40-60 psi. Both styles have the same goal but differ in the way they generate the flow, with the mechanical pump using engine motion while the electric unit spins an internal motor. Modern BMW electronics control pump speed with pulse width signals to reduce heat and prolong the life of the pump. Regular vigilance over the Fuel Pump and its circuit is what keeps the X3 ready for daily duty, and a silent Fuel Pump when the engine cranks is often an indication of electrical issues. Every BMW X3 today counts on the electric design for the supply of dependable high-pressure supply.

If you are looking for OEM BMW X3 Fuel Pump, we highly recommend to shop with us. Not only do we offer budget friendly prices, but we also provide fast delivery. In addition, we have a hassle-free return policy on all genuine BMW X3 Fuel Pump that come backed by the manufacturer's warranty.

BMW X3 Fuel Pump Parts Questions & Experts Answers

Fuel Pump Right
16117159604
Q: How to remove and install the fuel pump on BMW X3?
A:
For removing and installing the fuel pump, there is need to first unlatch the fuel tank service cap. Unscrew the connectors with advisable marginal force using a screwdriver. To remove the fuel pump wiring disconnected it with the help of BMW special tool 610307 which is present at the blue electrical connector positioned inside the tank. This is crucial for the simple reason that the connector on the fuel pump should not be removed at all because the replacement fuel pump comes with the connector attached to it. For reassembly it will be constructive to preserve the position of the wiring in the blue connector. When carrying out job within fuel tank, pull the tabs in the direction as shown to disconnect the line and to remove the fuel line, pull the tabs for quick connector. Pull the suction-jet line in the indicated direction to release the retaining lug, and simultaneous with this, push the lug to the rear of the fuel tank, thus lifting the fuel pump in conjunction with the surge chamber. For installation the sequence has to be done in the reverse order that it was removed and make sure the correct position of fuel pump before the guides and make sure the mounting lug lock into the fuel pump correctly. The fuel pump has an electrical wiring that should be plugged into the blue connector and the connectors for the fuel line must click into place. For the fuel pump not to be damaged it is recommended to refill the tank with at least 5 liters (1.5 gallons) of fuel before the engine is ignited after the work.
